- Supports Intel® Core 2 Quad/Core 2 Duo based processors in LGA775 package.
- Supports Intel® Yorkfield, Wolfdale.
- Supports FSB 1333/1066/800 MHz.
- Intel® P35 Chipset
- Supports FSB 800/1066/1333MHz.
- Supports dual channel, DDR2 667/800/1066 (OC).
Intel® ICH9R Chipset
- Hi-Speed USB (USB2.0) controller, 480Mb/sec, up to 12 ports.
- 4 SATAII with 2 eSATA ports with transfer rate up to 3Gb/s.
- PCI Master v2.3, I/O APIC.
- ACPI 2.0 compliant.
- Serial ATA RAID 0/1/5/10.
- Integrated AHCI controller.
- Supports four unbuffered DIMM of 1.8 Volt DDR2 SDRAM
- Supports up to 8GB memory size.
- Supports dual channel DDR2 memory architecture.
- Supports DDR2 667/800/1066 (OC) memory interface.
- Two PCI Express 16X slots with 1x16 and 1x4 operations (PCI Express Bus SPEC V1.0a compliant; supports CrossFire Technology)
- Two PCI Express x1 slots. (support PCI Express Bus specification v1.0a compliant)
- Two 32-bit v2.3 master PCI bus slots.
- Support 3.3v/5v PCI bus interface.
- One Ultra DMA 66/100/133 IDE controller integrated in Marvell® 88SE6111.
- Supports PIO, Bus Master operation modes.
- Can connect up to two Ultra ATA drives.
SATAII controller integrated in ICH9R and Marvell® 88SE6111 chipest
- Up to 300MB/sec transfer speed.
- Supports four SATAII ports and two eSATA ports by ICH9R.
- Supports AHCI controller with SATA RAID 0/1/5/10.
- Supports one SATAII port by 88SE6111.
