Hewlett Packard Enterprise FlexFabric 5940 48SFP+ 6QSFP28, Managed network switch, L2/L4, RJ-45/Mini-USB, IEEE 802.1s,IEEE 802.1w,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3ah,IEEE 802.3x, 288000 entries, 2160 Gbit/s

Name: hewlett-packard-enterprise-flexfabric-5940-48sfp-6qsfp28-managed-network-switch-l2-l4-rj-45-mini-usb
Brand: Hewlett Packard Enterprise
SKU: JH390A
Price: 28360.99 EUR
Availability: BackOrder

klik om te zoomen

Hewlett Packard Enterprise FlexFabric 5940 48SFP+ 6QSFP28, Managed network switch, L2/L4, RJ-45/Mini-USB, IEEE 802.1s,IEEE 802.1w,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3ah,IEEE 802.3x, 288000 entries, 2160 Gbit/s Vergelijk Pc-accessoires> Netwerk> Switches
Merk:	Hewlett Packard Enterprise
Artikelnr:	1202094
SKU:	JH390A
EAN:	0190017014821;190017014821
Productgroep:	Switches
Prijs:	€ 28.360,99
Voorraad:	Levertijd: ca. week 9

Social media:

Beschrijving

Specificaties

Beoordeling

The HPE FlexFabric 5940 Switch Series is a family of high-performance and low-latency 10GbE and 40GbE top-of-rack (ToR) data center switches. The 5940 Switch includes 100G uplink technology which is part of the HPE FlexFabric data center solution and is a cornerstone of the FlexNetwork architecture. The 5940 Switch is suited for deployment at the aggregation or server access layer of large enterprise data centers or at the core layer of medium-sized enterprises. It is optimized for high-performance server connectivity, convergence of Ethernet and storage traffic, and virtual environments.

What's new

VXLAN Layer 2 and Layer 3 gateway support.

Pre-configured switch bundles for deployment in the campus aggregation and core.

Comware 7 advanced modular operating system designed for high availability.

IRF supports of up to nine switches simplifies management by up to 88%.

EVPN, OpenFlow and SDN automate manual tasks and speed service delivery.

Features

High-Density, Advanced, Data Center Switches

The HPE FlexFabric 5940 Switch Series enables customers to scale their server-edge 10/40/100GbE ToR deployments with high-density 48 x 10GbE (SFP or BASE-T) with 6 x 40GbE ports, 48 x 10GbE (SFP or BASE-T) with 6 x 100GbE ports, and 32 x 40GbE ports, delivered in a 1RU design.

The HPE FlexFabric 5940 Switch Series is also available with a 2-slot modular version delivering 2 40GbE ports and a 4-slot modular version with 4 40GbE ports.

High-Performance Data Center Switching

The HPE FlexFabric 5940 Switch Series delivers up to 2.56 Tbps switching capacity for the most demanding data center applications.

It supports up to 1904 MPPS throughput for data-intensive environments.

Low latency, under 1µs for 40GbE, gives your network increased throughput.

VXLAN support for network virtualization and overlay solutions for improved flexibility.

Includes Open vSwitch Database (OVSDB) for dynamic VXLAN tunnel management.

Business Agility and Resilience with Comware 7

The HPE FlexFabric 5940 Switch Series delivers Hewlett Packard Enterprise Intelligent Resilient Fabric (IRF) <50 msec convergence time enabling faster application response time.

The In Service Software Update (ISSU) enables high availability with modular updates accomplished without a reboot or power cycle, in the background.

Simplicity and Lower TCO

HPE FlexFabric 5940 Switch Series simplifies switch management by up to 88% with 9-unit Intelligent Resilient Fabric (IRF).

No hidden costs with simple one license per switch for all OS features.

All switch ports are active and ready to use without need for activation licenses.

Beheerfuncties
Switch type	Managed
Switch-laag	L2-L4
Quality of Service (QoS)	Ja
Web-gebaseerd management	Ja
ARP-inspectie	Ja
Traffic-classificatie	Ja
Traffic shaping	Ja
System event log	Ja

Poorten & interfaces
Type basis-switching RJ-45 Ethernet-poorten	None
Aantal Gigabit Ethernet (koper)-poorten	1
Aantal moduleslots SPF	48
Aantal GSFP+-moduleslots	6
Vezel-optische connector	QSFP28, SFP+
Console port	RJ-45/Mini-USB
Aantal USB 2.0-poorten	1

Netwerk
Netwerkstandaard	IEEE 802.1S, IEEE 802.1W, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3ah, IEEE 802.3x
10G support	Ja

Optische vezel
Fiber ethernet cabling technologie	1000BASE-X, 10GBASE-R

Data-uitwisseling
MAC-adrestabel	288000 entries
Switchingcapaciteit	2160 Gbit/s
Throughput	1607 Mpps
Latentie (10 Gbps)	1 µs
Packet buffergeheugen	16 MB

Multicast-functies
Multicast-ondersteuning	Ja

Protocollen
Beheerprotocollen	SNMP, Telnet, FTP

Design
Rack-montage	Ja
Stapelbaar	Ja
Vormfactor	1U
Kleur van het product	Black
LED-indicatoren	Ja

Prestatie
Physical stacking (units)	9
Intern geheugen	4 GB
Flash memory	1 GB

Energie
Vermogenstoevoer inclusief	Nee
AC-ingangsspanning	90-264 V
AC-ingangsfrequentie	50/60 Hz
Ingangsspanning	40 - -75 V
Stroomverbruik (typisch)	196 W

Power over Ethernet (PoE)
Power over Ethernet (PoE)	Nee

Eisen aan de omgeving
Bedrijfstemperatuur (T-T)	0 - 45 °C
Relatieve vochtigheid in bedrijf (V-V)	10 - 90 %
Warmtedissipatie	887 BTU/h

Gewicht en omvang
Breedte	440 mm
Diepte	460 mm
Hoogte Hoogte van het product	44 mm
Gewicht	11000 g

Verpakking
Snelstartgids	Ja
Gebruiksaanwijzing	Ja
Gebruikershandleiding	Ja

Logistieke gegevens
Code geharmoniseerd systeem (HS)	85176990
